6061 and 6082 are the two most specified heat-treatable 6xxx-series aluminum alloys for structural work - 6061 aluminum plate and 6082 aluminum plate, plus extrusion, bar and tube. Both are Mg-Si alloys in T6 temper, but their chemistry, strength balance and typical supply form differ enough to change which grade a project should specify. This page compares the two structural aluminum alloys with numbers you can quote, not adjectives.
Scope: data shown for 6061-T6 (EN designation EN AW-6061 · AlMg1SiCu) and 6082-T6 (EN AW-6082 · AlSi1MgMn) in 6061 aluminum plate and 6082 aluminum plate, plus extrusion, bar and tube. Mechanical minima are typical per ASTM B209 / ASTM B221 / EN 485-2 and vary with product form, thickness and test direction. Final acceptance is by the mill test certificate (MTC).
6061 and 6082 Aluminum Plate and Alloy: Side-by-Side Comparison Table
All values are the comparable figure for each grade in T6 condition. Rows marked indicative are typical workshop ranges, not guaranteed specification minima.
| Metric | 6061-T6 | 6082-T6 |
|---|---|---|
| Tensile strength, UTS (MPa) | ≥310 (45 ksi) | ≥310 (45 ksi) |
| Yield strength, Rp0.2 (MPa) | ≥276 (40 ksi) | ≥255 (EN 485-2 ≥260; ASTM B221 ≥250) |
| Elongation at break (%) | ≥12 | ≥10 |
| Hardness, Brinell (HB) | 95 | 90 (indicative) |
| Magnesium, Mg (%) | 0.80–1.20 | 0.60–1.20 |
| Manganese, Mn (%) | ≤0.15 | 0.40–1.0 |
| Silicon, Si (%) | 0.40–0.80 | 0.70–1.30 |
| Density (g/cm³) | 2.70 | 2.70 |
| Welded joint efficiency (typical % of parent UTS) | 50–60 (indicative, as-welded) | 55–65 (indicative, as-welded) |
| Relative machinability (free-cutting brass = 100) | 50 (indicative) | 50 (indicative) |
| Relative cost (index) | 100 (base) | 103–106 (+3–6% indicative, market-dependent) |
| Best for | General structures, machined parts, frames, ladders | Heavy structures, bridges, trusses, cranes, lattice |
Standards referenced: ASTM B209 (plate/sheet), ASTM B221 (extruded bar/rod/shape), ASTM B211 (drawn bar/rod), EN 573-3 (composition), EN 485-2 (mechanical properties).
Aluminum Strength and Formability: 6061-T6 vs 6082-T6 Aluminum Plate
The headline tensile strength is the same - both reach ≥310 MPa UTS in T6. The difference is in yield and formability balance:
Yield: 6061-T6 holds ≥276 MPa, about 21 MPa above 6082-T6's ≥255 MPa (EN 485-2 lists ≥260 MPa). For a member designed by yield, 6061 carries slightly more load at equal section.
Ductility: 6061-T6 aluminum alloy reaches ≥12% elongation vs 6082-T6 ≥10%; in the soft O condition 6061 reaches ~25% elongation against ~20% for 6082 (indicative), so 6061 forms and bends at a tighter radius.
Formability drivers: 6082 carries more Si (0.70–1.30 vs 0.40–0.80) and far more Mn (0.40–1.0 vs ≤0.15). Higher Mn refines the structure for strength but reduces cold formability and raises the minimum bend radius.
If the part is bent, deep-drawn or heavily formed, 6061-T4 (UTS 241 MPa, yield 145 MPa, elongation 22%) gives more working margin before hardening. If the part is straight-cut and bolted, the yield gap is small.
Aluminum Corrosion Resistance: The Manganese Effect in 6xxx Alloy
Both are 6xxx-series aluminum alloys with good atmospheric corrosion resistance and a stable oxide film. The measurable differentiator is manganese:
Intergranular / exfoliation resistance: 6082's Mn content of 0.40–1.0% (vs 6061's ≤0.15%) disperses constituent particles and improves resistance to intergranular and exfoliation corrosion in humid or mildly aggressive atmospheres. For coastal or industrial exposure, 6082 is the more conservative pick.
General atmosphere: neither alloy needs coating for inland/urban service; anodizing or PVDF/powder coating is specified for appearance and added life, not as a corrosion necessity.
Pitting: both sit in the same pitting-potential band; chloride service should use the same design margins (thickness allowance, drainage) for either grade.
Welding and Machining Heat-Treatable 6xxx Aluminum Extrusion
Both aluminum alloys are weldable with 4043 or 5356 filler, but both are heat-treatable - welding softens the heat-affected zone:
Welded joint efficiency: as-welded, expect 50–60% (6061-T6) and 55–65% (6082-T6) of parent UTS (indicative). Post-weld heat treatment can recover toward ~80%, but most structural welds are used as-welded - design the joint for the degraded zone, not the T6 book value.
Filler choice: 5356 is used when the welded assembly must keep strength and color match after anodizing; 4043 flows better for thin sections. For 6082 in structural Eurocodes, 5356 / 5183 fillers are common.
Machining: both machine at about 50% of free-cutting brass (indicative index). 6061's lower Si keeps tool wear slightly lower; 6082's higher Si breaks chips a little better. Either is fine on standard CNC with sharp carbide and flood coolant.
Aluminum Alloy Cost: Where the 6082 Premium Comes From
The +3–6% premium for 6082-T6 over 6061-T6 is small because both are 6xxx precipitation-hardened alloys sharing the identical T6 route. The gap traces to a few measurable differences, shown as a price-index breakdown (6061-T6 = 100, mill base, indicative).
| Cost driver | 6061-T6 | 6082-T6 | Price effect (indicative) |
|---|---|---|---|
| Manganese content (corrosion-margin element) | ≤0.15% | 0.40–1.0% | +1–2% more Mn addition |
| Standard / regional demand | Broad general use | EU structural preference (EN 754 / EN 485-2) | +1–2% structural-spec demand premium |
| Extrusion die / stock availability | Very broad | Slightly narrower range | +1–2% die / stock mix |
| Temper process | T6 | T6 | 0% same precipitation route |
| Composite relative price index | 100 (base) | 103–106 | +3–6% indicative, market-dependent |
The drivers add to about +3–6%: 6082 carries 0.40–1.0% manganese against 6061's ≤0.15%, it is the preferred alloy in European structural standards (so a regional demand premium), and its die/stock mix is slightly narrower. Both share the identical T6 precipitation route, so there is no heat-treatment cost gap - which is exactly why the premium stays small and rarely decides a project by itself. It matters mainly at high volume or where 6082's Mn corrosion margin removes a later coating step. Where 6061 already meets yield and formability, paying the 6082 premium is hard to justify on strength alone, because peak UTS is identical (≥310 MPa for both).
Indices are indicative mill base-price ratios (per kg, ex-works), not a quotation. Our quotations are benchmarked to the SMM (Shanghai Metals Market) aluminum price. Actual premium varies with section, gauge, order volume and the SMM aluminum price - request a side-by-side quote for your exact form and temper.
When to Choose 6061-T6 or 6082-T6 Aluminum Plate
Choose 6061-T6 aluminum alloy when
Yield matters more than Mn-driven corrosion margin: need ≥276 MPa yield at T6.
The part is machined - 6061-T6 aluminum extrusions, flanges and ASTM B221 angles are the classic stock-in-trade - or bent, punched and deep-drawn (higher elongation, tighter bend radius).
You need the widest off-the-shelf stock in plate, extrusion, bar and tube - from structural sections to aerospace aluminum tube - under a single global specification (ASTM B209/B221).
Choose 6082-T6 structural aluminum alloy when
The structure faces humid, coastal or industrial atmosphere and you want the Mn corrosion margin (Mn 0.40–1.0%).
The job is a heavy welded lattice - 6082-T6 aluminum beams and extrusions for bridge, crane and truss structure - where European specs (EN 485-2 / EN 573-3) and 5356/5183 welding practice are mandated.
Extruded structural aluminum sections are specified to EN and the project already standardizes on 6082.
FAQ: 6061 and 6082 Aluminum Alloy
Q: Is 6082 stronger than 6061?
A: In peak tensile strength, no - both are ≥310 MPa UTS in T6. 6061-T6 has the higher yield (≥276 vs ≥255 MPa); 6082's edge is corrosion margin from higher Mn, not raw strength.
Q: Can I substitute 6082 for 6061?
A: For bolted structures with the same section, usually yes, with a small yield reduction (≈21 MPa) and a +3–6% cost. For formed parts, check bend radius - 6082 needs a wider radius. Always re-run the load case and confirm the welding/coating spec.
Q: Which aluminum alloy welds better?
A: Both weld similarly with 4043/5356; as-welded joint efficiency is ~50–60% (6061) vs ~55–65% (6082), indicative. Neither keeps full T6 strength through the weld - design for the HAZ.
Q: Which is cheaper?
A: 6061-T6 is the base (index 100); 6082-T6 runs about +3–6% indicative, market-dependent.
