When engineers design structures for marine, offshore, or cryogenic environments, standard aluminum pipes often fail. Saltwater pitting, stress corrosion cracking, and the loss of strength at welded joints are the most common reasons for structural failure.
The 5086 aluminum pipe is specifically engineered to eliminate these risks. As a premium 5000-series aluminum-magnesium alloy, 5086 delivers exceptional corrosion resistance in seawater and industrial chemicals, combined with high mechanical strength that remains intact even after heavy welding.
At GNEE, we manufacture and supply industrial-grade aluminum alloy 5086 pipes globally. Whether you need ASTM B241 seamless tubing for pressure vessels or ASTM B429 extruded pipes for structural framing, we provide reliable, mill-certified materials designed to keep your projects safe.
What Makes 5086 Aluminum Alloy Pipe Unique?
The core strength of 5086 lies in its chemical makeup. With a magnesium content ranging from 3.5% to 4.5%, this alloy acts as a true "marine grade" material.
- Superior Corrosion Resistance: 5086 aluminum pipes do not require protective coatings or paint to survive in saltwater environments. The alloy naturally forms a dense, self-repairing oxide layer that prevents pitting.
- Excellent Weldability: Unlike the 6000-series alloys which lose massive amounts of strength when welded, 5086 retains excellent mechanical properties across the weld seam. This makes it the top choice for welded boat hulls and pressure tanks.
- Non-Heat Treatable: The strength of 5086 is achieved through cold working and strain hardening (such as H111 or H116 tempers), significantly reducing fabrication complexity and costs.
Equivalent Grades for 5086 Aluminum
If your engineering drawings specify European or ISO standards, refer to our equivalent grade chart:
UNS: A95086
Werkstoff Nr. (DIN): 3.3545
EN Standard: EN AW-5086 / EN AW-AlMg4
ISO: AlMg4
Chemical Composition of 5086 Aluminum Pipe
The high magnesium and controlled manganese levels give this pipe its toughness.
| Element | Composition (%) |
| Magnesium (Mg) | 3.50 – 4.50 |
| Manganese (Mn) | 0.20 – 0.70 |
| Chromium (Cr) | 0.05 – 0.25 |
| Silicon (Si) | Max 0.40 |
| Iron (Fe) | Max 0.50 |
| Zinc (Zn) | Max 0.25 |
| Titanium (Ti) | Max 0.15 |
| Copper (Cu) | Max 0.10 |
| Aluminum (Al) | Balance |
Mechanical Properties of Aluminum Alloy 5086 Piping
(Note: Values based on H111 / H116 standard tempers)
| Property | Value |
| Tensile Strength | 275 - 350 MPa |
| Yield Strength (Proof Stress) | Min 125 MPa |
| Elongation | Min 12% |
| Hardness (Brinell) | 75 HB |
Types of 5086 Aluminum Pipes Manufactured by GNEE
Different projects require different manufacturing methods. We stock and produce various pipe types to match your exact working pressure and budget.
1. ASTM B241 5086 Seamless Aluminum Pipe
Manufactured by extruding the aluminum over a piercing mandrel. This process leaves zero weld seams in the pipe wall. It is mandatory for high-pressure oil and gas transmission, cryogenic fluids, and critical marine systems where a seam rupture is unacceptable.
2. Extruded 5086 Aluminum Alloy Pipe (ASTM B429)
Produced through a porthole die. While it contains microscopic metallurgical seams, it is incredibly strong and cost-effective. It is heavily used in structural applications like ship superstructures, scaffolding, transmission towers, and heavy-duty vehicle frames.
3. Large Diameter Welded 5086 Aluminum Pipe
For fluid transfer systems requiring an outer diameter larger than 16 inches, we roll and weld premium 5086 aluminum plates. All weld seams are 100% X-ray inspected to guarantee leak-proof performance.
5086 Aluminum Pipe Major Application Industries
Because of its unique cold-temperature strength and saltwater resistance, 5086 is heavily consumed by the following sectors:
- Shipbuilding & Marine: Hull frameworks, deck houses, offshore oil rigs, and seawater piping systems.
- Pressure Vessels & Gas Lines: Cryogenic storage tanks (LNG transport), due to the fact that aluminum 5086 actually becomes stronger as temperatures drop below freezing.
- Transportation: Armor plates for military vehicles, railway tank cars, and heavy-duty dump truck chassis.
Strict Quality Testing & Export Packaging
At GNEE, we do not guess about quality. Every batch of 5086 aluminum piping undergoes rigorous inspection before leaving our factory.
Testing Procedures:
- Positive Material Identification (PMI)
- Hydrostatic Testing (for seamless pressure pipes)
- Ultrasonic Flaw Detection
- Tensile & Hardness Testing
- Third-Party Inspection (SGS, TUV, DNV, or ABS upon request).
Seaworthy Packaging: To prevent scratches and oxidation during ocean transit, pipes are capped at the ends, wrapped in waterproof poly-plastic, and packed securely into fumigated wooden boxes or hexagonal steel-strapped bundles.
Why Buy 5086 Aluminum Pipes from GNEE?
We are a direct factory and a global exporter, removing the middlemen from your supply chain.
- Global Reach: We export to over 80 countries, fully understanding complex customs and import requirements.
- Custom Fabrication: We do not just sell raw pipes. We offer cut-to-length, beveling, and heavy bending services based on your CAD drawings.
- Massive Stock: Standard sizes are kept in stock to ensure rapid delivery for urgent shipyard repairs.
Get a Quick Quote Today
Stop wasting time with suppliers who cannot provide material certifications. At GNEE, we deliver pure, verifiable quality.
Send us your inquiry today to receive :
- A precise, highly competitive price quote within 24 hours.
- A Free EN 10204 3.1 Mill Test Certificate (MTC) sample for your engineers to review.
- Support for small trial orders to verify our quality.
Email us your required OD, Thickness, Length, and Quantity, and our technical sales team will assist you immediately.
