Henan Gnee New Material Co., Ltd. is one of the most reliable manufacturers and suppliers of aluminum foil for air duct in China. With abundant experience, we warmly welcome you to wholesale high quality aluminum foil for air duct in stock here from our factory. Good service and reasonable price are available.
Foil duct is made of stretched pure aluminum foil, which is continuously and tightly clamped by a spiral. Because aluminum has oxidizing properties, it is usually covered with a layer of glue during production to isolate the oxidation reaction between the aluminum and oxygen in the air.
Aluminum flexible ducting is produced for low and medium pressure heating, cooling, ventilation, exhaust and air conditioning systems.
Single-layer and double-layer aluminum foil ducts are the more common types on the market. It is popular because it is cheap, flexible, corrosion-resistant and can withstand temperatures up to 150 degrees Celsius. And most people prefer double-layer air ducts because they are relatively durable.
| Specification | Range/Type |
|---|---|
| Thickness | 0.006mm - 0.2mm |
| Width | 50mm - 1600mm |
| Alloy | 8011, 1100, 1050, 1060, 3003, 8079, 8006, 3004, 8021 |
| Temper | O, H18, H19, H22, H24, H26 |
| Packaging | Free Fumigated wooden box |
characteristic:
1. Durable structure
2. Maximize cooling system efficiency
3. No special tools are required for cutting or fixing
4. Highly flexible and space-saving
5. Excellent performance and operability
6. Corrosion-resistant and mildew-proof
7. No toxic gases will be emitted in case of fire
8. Good air tightness
9. Good noise reduction effect.
Packing & Delivery
1. Fumigated wooden box.
2. Iron pallets.
3. Water proof papers.
4. Interleaved paper.
5. PVC film.
6. Standard export sea-worthy packing or according to your requirement.
Since the aluminum foil needs to be embossed or coated first, the surface requirements are generally not very strict, but the plate shape is required to be smooth and the surface is clean.
Usage method: After aluminum foil is embossed or coated, it is compounded with phenolic board or polyurethane board, usually double-sided. The finished product specifications are 20mm thick, 1200mm wide, and 4000mm long.
GNEE's award certificate.
Aluminum foil ducts have the following advantages compared with traditional composite ducts:
1. Super surface hardness can effectively resist collision and impact. The impact resistance is comparable to that of iron air ducts and exceeds that of inorganic fiberglass air ducts, avoiding damage caused by cross construction;
2. Class A is non-combustible, smoke-free and non-toxic, and is the best fire-proof and smoke-exhaust air duct;
3. Good thermal insulation, which can greatly reduce the heat loss of air conditioners. The thermal conductivity of phenolic composite air duct is 0.016~0.036W/(m·k), while the thermal conductivity of galvanized steel air duct and fiberglass air duct is much larger.
4. Light weight and high strength, 2.5kg/㎡, slightly heavier than aluminum foil phenolic foam composite air duct, 1/3 of iron air duct; light weight, can reduce building load, and easy to install.
5. It has strong weather resistance and is suitable for outdoor air ducts. It can withstand long-term wind, sun and rain.
