Gnee Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of 6061 aerospace aluminum bar rod in China. With abundant experience, we warmly welcome you to wholesale high quality 6061 aerospace aluminum bar rod in stock here from our factory. Good service and reasonable price are available.
6061 Aerospace Aluminum Bar Rod Description
6061 Aerospace Aluminum Bar Rod provided by GNEE
6061 aerospace alumunum CF bar
6061 aerospace alumunum extruded bar
6061 aerospace alumunum forged bar
Chemical composition of 6061 aluminum alloy
| Element | Composition % |
| Si | 0.40-0.80 |
| Fe | 0.70 |
| Cu | 0.15-0.40 |
| Mn | 0.15 |
| Mg | 0.8-1.20 |
| Ti | 0.15 |
| Al | Remainder |
Mechanical property of 6061 aluminum bar rod
| Temper | Diameter | Physical Property |
| T4 | 0.125" - 7" (3.175mm - 177.8mm) | Yield Strength: 34 ksi (235 MPa) Tension Strength: 45 ksi (310 MPa) Elongation: 10% Hardness: 95 HRB |
| 0 | 0.125" - 7" (3.175mm - 177.8mm) | Yield Strength: 8 ksi (55 MPa) Tension Strength: 18 ksi (125 MPa) Elongation: 25% Hardness: 65 HB |
| T6/T651 | 0.125" - 7" (3.175mm - 177.8mm) | Yield Strength: 45 ksi (310 MPa) Tension Strength: 40 ksi (275 MPa) Elongation: 8% Hardness: 95 HRB |
| T451 | 0.250" - 12" (6.35mm - 304.8mm) | Yield Strength: 40 ksi (275 MPa) Tension Strength: 68 ksi (470 MPa) Elongation: 12% Hardness: 120 HB |
specification Of 6061 Aerospace Aluminum Bar
|
Product
|
Aluminium bar / rod
|
|||
|
Shape
|
6061 aerospace aluminum round bar, Angle bar, Channel bar, 6061 aerospace aluminum square bar, 6061 aerospace aluminum flat bar, 6061 aerospace aluminum hex bar and profiles
|
|||
|
Standard
|
GB/T 3191-1998,ASTM B221M-05a,JIS H4040-2006,ASTM B211M-03
|
|||
|
Grade
|
6000 series
|
6061
|
||
|
Temper
|
O,T3,T4,T5,T6,T451,T651,etc
|
|||
|
Shape
|
Round bar
|
Square bar
|
Flat bar
|
Hexagon Bar
|
|
Size
|
1.0-300mm
|
10x10-200x200mm
|
2x10-120x240mm
|
S1-S300mm
|
|
Surface
|
Anodizing, brush, sand blast, powder coating, polished, mill ,etc.
|
|||
|
Package
|
Standard export seaworthy or as customers' requirements
|
|||
|
Price Terms
|
Ex-Work,FOB,CFR,CIF,FCA,etc.
|
|||
|
Payment Terms
|
TT,L/C at sight ,western Union,etc.
|
|||
According to the above characteristics, 6061 aluminum alloy rods are suitable for various industrial structural parts that require certain strength, weldability and high corrosion resistance, such as manufacturing trucks, trusses, ships, trams, furniture, mechanical parts, precision machining, and industrial materials.
6063 aluminum alloy metal rod is a typical representative of 6 series alloy (Al-Mg-Si). It has excellent extrudability and weldability and is the preferred material for building door and window profiles.
Q&a
FAQ
Q1: How can we guarantee quality?
A:1 ). We can provide samples for free.We can send the samples by TNT,DHL,FEDEX,EMS,UPS or to your warehouse. 2 ). Always a pre-production sample before mass production. 3 ). Always final Inspection before shipment.
Q3: How long will it take to produce my order?
A:Our normal produce time is 7-25 working days,depend on your order.
A:Of course, if you don't work with a shipping company.We have a long-term cooperation of the transport team can provide you with lower prices, better service.
